Shielded Power Inductor

| | | | | | | | | | | | | | |

ASPI-4020HI

FEATURES:

ABRACON IS

ISO 9001 / QS 9000

CERTIFIED

ABRACON IS

ISO 9001:2008

CERTIFIED

30332 Esperanza, Rancho Santa Margarita, California 92688

Revised: 01.30.14

Visit www.abracon.com for Terms & Conditions of Sale

4.5 x 4.1 x 2.1mm

• High saturation current

• Low loss due to low DC resistance

• Low profile with max thickness 2.1mm

•100% lead free and meeted RoHS standard

• Suitable for reflow soldering

• Highly reliable SMD package

STANDARD SPECIFICATIONS

Abracon P/N:

ASPI-4020HI Series

Operating Temperature & Humidity:

Storage Temperature & Humidity:

Test Conditions

PART NUMBER IDENTIFICATION

APPLICATIONS:

Part Number

ASPI-4020HI-

Inductance Code

L(uH)

Tolerance

DCR (mΩ)

max.

Isat (A)

max.

Irms (A)

max.

ASPI-4020HI-R10

0.10

M

4.0

22.0

12.0

ASPI-4020HI-R22

0.22

M

6.6

12.5

9.0

ASPI-4020HI-R47

0.47

M

14

9.5

7.0

ASPI-4020HI-R56

0.56

M

16

8.5

6.5

ASPI-4020HI-1R0

1.0

M

27

7.0

4.5

ASPI-4020HI-1R5

1.5

M

46

6.0

4.0

ASPI-4020HI-2R2

2.2

M

58

5.0

3.0

ASPI-4020HI-3R3

3.3

M

87

4.0

2.5

Inductance (L)

a. Test equipment: Agilent4284A

b. Test frequency: 100kHz, 0.25Vrms

-55˚C to +155˚C

+25±3˚C, 80% RH max (In tape and reel)

ASPI- 4020HI -

-

Inductance Tolerance

M: ±20%

Packaging

T: Tape and Reel

(3.5kpcs reel)

Inductance Code

Please refer to the

table above

• DC/DC converters in LED driver, Notebook, Tablet,

Desktop and Server

• Low profile, high current power supplies
