CFPB

Illuminated Pushbutton Switches

RoHS Compliant

■ SpeciÄcations

Rating

Max.

DC5V 5mA or DC20V 1mA

Min.

DC5V 1mA

Initial Contact Resistance

200

Ω Max  （20mV 1.5mA 1kHz Max）

Dielectric Strength

250VAC 1 minute

（100VDC）

Travel

1.5mm

（11/12mm sq.） 1.3mm（6/9mm sq.）

Operating Force

1.7

±0.5N (11/12mm sq)

1.3 +0.6/-0.4N (6/9mm sq.)

Electrical Life

500,000 operations at maxrating

（11/12mm sq.）

300,000 operations at max. rating

（6/9mm sq.）

Operating Temperature Range

−10℃∼＋60℃

Storage Temperature Range

−25℃∼＋70℃

※Information on LED drive circuit are shown on the next page.

■ Features

1. Full Surface Illumination by LED.

2. Conductive Rubber Contact For Soft and

Quiet Operation

3. Available in Four Sizes

6mm sq., 9mm sq., 11mm sq., 12mm sq.

■Part Numbering

Pushbutton

OFF −（ON）

1 pole

W

B1

C

C

1

W

1

Series Code & Actuator

Button Dimension

Button Color

Packaging Specifications

W

P

1

1

2

6

9

LED Color

Terminal Style

Number of Poles

Number of Poles

Type

Combination

1R

1

2

1

3

1

4

1

5

1

5

1

5

2R

1O

3O

1W

4W

1B

5B

1G

5G

1Y

R

O

W

B

G

Y

5Y

Non-illuminated

Red

Orange

Yellow

Green

Green

Green

Red

Orange

White clear

Blue

Green

Yellow

Non-illuminated

Non-illuminated

Non-illuminated

Non-illuminated

Non-illuminated

LED Color

Button Color

Button Dimension

Packaging Specifications

Code

Fig.

Fig.

C

Straight

Terminal Style

Code

Code

Tray

□11mm sq.

□12mm sq.

□6mm sq.

□9mm sq.

C

Switching Function

Switching Function

Code

Switching

Function

Part No.

CFPB

−1CC−■■■W

OFF

（ON）

Connecting Terminals

−

1

−2

※Exclude Non - illuminated type.

LED

Characteristics

Part No.

CFPB

−1CC−■■■W

Connecting Terminals

3

−4

（ON）

：Momentary

■Switching function

■LED Characteristics
