Features

Compliant with AEC-Q200 Rev-C-Stress

Test Qualification for Passive Components

in Automotive Applications

Operating temperature range up to 125 °C

Low thermal derating factor

Higher hold currents at elevated

temperature

Choice of operating cuttents

RoHS compliant* and halogen free**

*RoHS Directive 2002/95/EC Jan 27 2003 including annex and RoHS Recast 2011/65/EU June 8,2011.

Specifications are subject to change without notice.

Customers should verify actual device performance in their specific applications.

Electrical Characteristics

Model

V max.

Volts

I max.

Amps

Ihold

I trip

Resistance

Max. Time

To Trip

Tripped

Power

Dissipation

Amperes

at 23 °C

Ohms

at 23 °C

Amperes

at 23 °C

Seconds

at 23 °C

Watts

at 23 °C

Hold

Trip

RMin.

R1Max.

(Post Trip)

Max.

Typ.

PRCP-RHT070

16

40

0.7

1.4

0.3

0.8

3.5

4.0

1.4

PRCP-RHT200

16

100

2.0

3.8

0.045

0.110

12.5

3.0

1.4

PRCP-RHT450

16

100

4.5

7.8

0.022

0.054

22.5

3.0

3.6

PRCP-RHT650

16

100

6.5

12.0

0.011

0.026

32.5

5.5

4.3

PRCP-RHT750

16

100

7.5

13.1

0.0094

0.022

37.5

7.0

4.5

PRCP-RHT1300

16

100

13.0

24.0

0.0041

0.010

60.0

13.0

6.9

Environmental Characteristics

Operating Temperature

-40 °C to +125 °C

Storage Tempetature............................................-40 °C to +85 °C

Passive Aging .......................................................+85 °C, 1000 hours............................................... ±15 % typical resistance change

Humidity Aging......................................................+85 °C, 85 % R.H. 1000 hours..............................

Thermal Shock......................................................MIL-STD-202, Method 107,...................................

+125 °C to -40 °C, 10 cycles

Vibration ...............................................................MIL-STD-883C, Method 2007.1, Condition A ....... No change

Test Procedutes And Requirements For Model PRCP-RHT Series

Accept/Reject Criteria

Test Conditions

Test

Visual/Mech.......................................................... Verify dimensions and materials........................... Per PRCP physical description

  

Hold Current......................................................... 30 min. at Ihold..................................................... No trip

Trip Cycle Life....................................................... Vmax, Imax, 100 cycles........................................ No arcing or burning

Trip Endurance..................................................... Vmax, 48 hours..................................................... No arcing or burning

Solderability........................................................... MIL-STD-202, Method 208.................................... 95 % min. coverage

Thermal Derating Chart - I hold (Amps)

Model

Ambient Operating Tempetature

-40 °C

-20 °C

0 °C

23 °C

40 °C

50 °C

60 °C

70 °C

85 °C

125 °C

PRCP-RHT070

0.95

0.87

0.79

0.7

0.62

0.56

0.51

0.47

0.39

0.17

PRCP-RHT200

2.71

2.49

2.26

2.00

1.77

1.60

1.46

1.34

1.11

0.49

PRCP-RHT450

6.1

5.6

5.1

4.5

4.0

3.6

3.3

3.0

2.5

1.1

PRCP-RHT650

8.8

8.1

7.4

6.5

5.7

5.3

4.8

4.3

3.6

1.6

PRCP-RHT750

10.2

9.4

8.6

7.5

6.6

6.1

5.6

5.0

4.1

1.9

PRCP-RHT1300

17.7

16.3

14.8

13.0

11.4

10.5

9.6

8.6

7.2

3.3

RH750

4180S

How to Order

PRCP - RHT 750 - __

Product Designator

Series

RHT = High Temperature

Radial Leaded Component

Hold Current,Ihold

070 - 1300 (0.70 - 13.00 Amps)

Packaging Options

- = Bulk Packaging

- 2 = Tape and Reel*

*Packaged per EIA 486-B

.........................................

±15 % typical resistance change

±10 % typical resistance change

Resettable fault protection of general

electronic equipment

**COPAL follows the prevailing definition of “halogen free” in the industry. COPAL considers a product to be “halogen free” if (a) the Bromine (Br) content is 900 ppm or less;

(b) the Chlorine (CI) content is 900 ppm or less; and (c) the total Bromine (Br) and Chlorine (CI) content is 1500 ppm or less.

The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
