PS86/PS87

RESSURE SWITCHES

PRESSURE SWITCH

30

0

–0.3

16.8 0.1

1 0.1

16

25

Label

(41)

G 3/8

(PF 3/8)

Pressure port

1.6

Hysteresis setting

VR

Indicator LED

Pressure setting VR

φ

φ

4-core cable

AWG26 ULNo.2851 L = 2000 20

(

5.0)

φ

DIFF.

ON

OConfigurations of joint G3 (G 3/8) type

PRESSURE SWITCH

Hysteresis setting

VR

Indicator LED

Pressure setting VR

30

0

–0.3

15

26

Label

(41)

R 1/4

(PT 1/4)

Pressure port

  1.6

φ

DIFF.

ON

4-core cable

AWG26 ULNo.2851 L = 2000 20

(

5.0)

φ

OConfigurations of joint R2 (R 1/4) type

Drip-proof cover

ODrip-proof cover type

Unless otherwise specified, tolerance :

± 0.5 (Unit: mm)

Wire color

Red

Black

White

Green

Connection

Power

B

Power

C

Output

B

Output

C

Please make sure that the drip-proof cover is properly

placed over the main body and the cable.
