EB2 SERIES

DATA SHEET ER0016EJ5V0DS00

PART NUMBER SYSTEM

EB2 - 5 S NUH - L

EB2 series

Nominal voltage

3, 4.5, 5, 6, 9, 12, 24 volts

Latch type

Nil : Non latch type

S : Single coil latch type

T : Double coil latch type

Packaging code

Nil : Tube type

L

: Embossd carrying type (L type)

R : Embossd carrying type (R type)

Feature

Nil

: Standard type

NU

: UL recognized, CSA certified standard type

NUH : Minimum footprint type ∗

NUE : Low profile type ∗

NUL : Ultra-low profile type ∗

∗ UL recognized, CSA certified type

OUTLINE DRAWINGS AND DIMENSIONS

PAD LAYOUTS (bottom view)

14.3 MAX.(0.56)

9.3 MAX.(0.37)

14.3 MAX.(0.56)

9.3 MAX.(0.37)

11.5(0.45)

7.62(0.30)

9.3(0.37)

7.62(0.30)

2.54

(0.1)

2.54

2.54

2.54

Note. General tolerance:

±0.2 (±0.008)

Note. General tolerance:

±0.1 (±0.004)

2.54

(0.1)

2.54

2.54

2.54

EB2-..NUH

EB2-..

EB2-..NU

EB2-..NUE

Unit: mm (inch)

EB2-..NUH

EB2-..

EB2-..NU

EB2-..NUE

EB2-..NUL

Unit: mm (inch)

2.54(0.1)

1.0(0.04)

2.54(0.1)

1.0(0.04)

14.3 MAX.(0.56)

9.3 MAX.(0.37)

11.5 (0.45)

7.62 (0.30)

2.54

(0.1)

2.54

2.54

2.54

EB2-..NUL

PIN CONFIGURATIONS (bottom view)

12

3

4

5

10 9

8

7

6

12

3

4

5

12

3

4

5

10 9

8

S

R

S

R

76

10 9

8

7

6

Index mark of relay derection

Non-latch type

(not energized position)

Single coil latch type

(reset position)

S : Coil polarity of set (operate)

R : Coil polarity of reset (release)

Double coil latch type

(reset position)
