PRODUCT FAMILY DATA SHEET

CP41A-RDS/ADS

CP41A-RFS/AFS

CP41A-RHS/AHS

Copyright © 2010 Cree, Inc. All rights reserved. The information in this document is subject to change without notice.

Cree, the Cree logo and XLamp are registered trademarks of Cree, Inc.

FEATURES

• Size (mm): 7.6 x 7.6

• Color and Typical Dominant

Wavelength:

Red (624nm)

Amber(591nm)

CP41A-RDS:(4400-8730)

CP41A-RFS:(4400-8730)

CP41A-RHS:(4400-8730)

CP41A-ADS:(4400-11000)

CP41A-AFS:(4400-11000)

CP41A-AHS:(4400-11000)

• Lead - Free

• RoHS Compliant

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

www.cree.com/xlamp

Copyright © 2016 Cree, Inc. All rights reserved. The information in this document is subject to change without notice. Cree and

the Cree logo are registered trademarks of Cree, Inc.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

APPLICATIONS

•ChannelLetter

•Amusement

PRODUCT DESCRIPTION

This revolutionary package design

allows the lighting designer to reduce

the number of LEDs required and

provide a more uniform and unique

illuminated appearance than with

other LED solutions.

Thisispossiblethroughtheefficient

optical-package design and high-

current capabilities. The low-profile

package can be easily coupled with

reflectors or lenses to efficiently

distribute light and provide the

desired lit appearance. This product

family employs green and blue LED

materials, which allows designers

to match the color of many lighting

applications such as vehicle signal

lamps and amusement lighting.
