1 / 4 page  30332 Esperanza, Rancho Santa Margarita, California92688 tel 949-546-8000| fax 949-546-8001| www.abracon.com Revised: 11.05.14 Visit www.abracon.comfor Terms & Conditions of Sale CERTIFIED ABRACON IS CERTIFIED ABRACON IS ISO9001:2008 CERTIFIED |||| | | | | | | | | | | | 3.2 x 2.5 x 0.85 mm APPLICATIONS: FEATURES: STANDARD SPECIFICATIONS: Low Jitter MEMS Technology! . • Consumer Electronics • Storage Area Networks • SATA, SAS, Fibre Channel • Passive Optical Networks • EPON, 10G-EPON, GPON, 10G-PON • Ethernet • 1G, 10GBASE-T/KR/LR/SR, and FCoE • PCI Express • Ultra Miniature Pure Silicon • Pin Configurable LVPECL Dual output • Low Jitter (Period Jitter RMS 3ps typical) • Low Integrated Phase Jitter 2ps max • Excellent Shock & Vibration Immunity TM Clock Oscillator Low Jitter Pin Configurable LVPECL Dual Output 3G MEMS ULTRA MINIATURE PURE SILICONTMCLOCK OSCILLATOR ASEMDLP LOW JITTER PIN CONFIGURABLE DUAL LVPECL OUTPUT ASEMDLP Ordering Info Freq (MHz) Freq Select Bits [FS2, FS1, FS0] – Default is [111] 000 001 010 011 100 101 110 111 Frequency Configuration 1 fOUT1 106.25 100 125 156.25 156.25 156.25 125 400 fOUT2 25 100 125 156.25 25 125 25 200 Custom Configuration fOUT1 Contact Abracon for customized configurations fOUT2 Frequency select bits [FS2, FS1, FS0] are weakly tied high so if left floated, the default setting will be [111] and the device will output the associated frequency highlighted in Bold. If other frequency combinations are required, please contact Abracon for customized configuration. Please see the configurable frequency range in the section 2.0 Parameters Minimum Typical Maximum Units Notes Configurable frequency range 10 ----- 460 MHz Commercial, Industrial temp range Operating Temperature -20 ----- +70 °C See options Storage Temperature -55 ----- +150 °C Overall Frequency Stability*1 -50 ----- +50 ppm See options Supply Voltage (Vdd) +2.25 ----- +3.6 V Startup Time ----- ----- 5 ms Enable Time ----- ----- 20 ns Disable Time ----- ----- 5 ns Disable Current ----- 21 23 mA Tri-state Function (Standby/Disable) "1" (VIH≥0.75*Vdd) or Open: Oscillation "0" (VIL<0.25*Vdd) : Hi Z V 40kΩ pull-up resistor embedded Aging -5.0 ----- +5.0 ppm First year Supply Current (Idd) ----- 89 ----- mA RL=50Ω, 156.25MHz Output Logic Level VOH Vdd-1.08 ----- ----- V RL=50 Ω VOL ----- ----- Vdd-1.55 Peak to Peak Output Swing ----- 800 ----- mV Single-Ended Rise Time Tr ----- 250 ----- ps RL=50 Ω, CL=2pF 20% to 80% Fall Time Tf ----- 250 ----- ps Duty Cycle 48 ----- 52 % Differential Pre-programmed Output Frequency Configuration Key Electrical Specifications *1. Frequency stability includes frequency variations due to initial tolerance, temp. and power supply voltage Moisture Sensitivity Level – MSL 1 Pb RoHS/RoHS II compliant |
