30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 11.05.14

Visit

CERTIFIED

ABRACON IS

CERTIFIED

ABRACON IS

ISO9001:2008

CERTIFIED

|||| | | | | | | | | | | |

APPLICATIONS:

3.2 x 2.5 x 0.85 mm

Key Electrical Specifications (continued)

PHASE JITTER

(left blank if standard)

ABSOLUTE MAXIMUM RATINGS

ASEMDLP

LOW JITTER PIN CONFIGURABLE DUAL LVPECL OUTPUT

ASEMDLP

OPTIONS AND PART IDENTIFICATION:

Parameters

Minimum

Typical

Maximum

Units

Notes

-----

2.5

-----

ps

F01=F02= 156.25MHz

-----

0.25

2

ps

200kHz ~ 20MHz,

156.25MHz

-----

0.38

2

100kHz ~ 20MHz,

156.25MHz

-----

1.70

2

12kHz ~ 20MHz,

156.25MHz

Item

Minimum Maximum Unit Condition

Supply Voltage

-0.3

+4.0

V

Input Voltage

-0.3

V

Junction Temp.

-----

+150

°C

Storage Temp.

-55

+150

°C

Soldering Temp.

-----

+260

°C

40sec max

ESD

HBM

MM

CDM

4,000

400

1,500

V

0.0

0.5

1.0

1.5

2.0

2.5

0

200

400

600

800

1000

Low-end of integration BW: x kHz to 20 MHz

156MHz-LVPECL

212MHz-LVPECL

320MHz-LVPECL

410MHz-LVPECL

Frequency

Combination

Freq

(MHz)

Freq Select Bits [FS2, FS1, FS0] – Default is [111]

000

001

010

011

100

101

110

111

Standard

Configuration

106.25

100

125

156.25

156.25

156.25

125

400

25

100

125

156.25

25

125

25

200

Custom

Configuration

Contact Abracon for customized configurations

Frequency combination and default frequency is customized upon request. Please contact Abracon for the frequency combinations.

ASEMDLP - - -

Operating Temp.

Blank: -20°C ~ +70°C

L: -40°C ~ +85°C

Overall Freq. Stability

Blank: ±50ppm

R: ±25 ppm

Packaging

Blank: Tube (110pcs / Tube)

T: Tape & Reel (1kpcs / reel)

T3: Tape & Reel (3kpcs / reel)

T5: Tape & Reel (5kpcs / reel)
