PART IDENTIFICATION:

WIRE WOUND INDUCTOR - CERAMIC or FERRITE

AISC-0805(F)

30332 Esperanza, Rancho Santa Margarita, California92688

Visit

CERTIFIED

ABRACON IS

CERTIFIED

ABRACON IS

ISO9001:2008

CERTIFIED

2.29 x 1.73 x 1.55mm

Revised: 09.09.14

*Ceramic core only

AISC-0805

-

-

Inductance Tolerance

G: ±2%*

J: ±5%

K: ±10%

M: ±20%

Inductance Code

Please refer to the

table above

Core Material

Blank: Ceramic

F: Ferrite

Packaging

T: Tape and Reel

(2kpcs / reel)

OUTLINE DRAWING:

Dimension: inches / mm

Part Number

L(nH)

@Test Freq.

Tolerance

(±%)

Q, Min

@Test Freq.

SRF Min

(MHz)

( Ω )

(mA)

AISC-0805F-100

10000@2.5MHz

5,10,20

10@2.5MHz

30

4.70

98

AISC-0805F-150

15000@2.5MHz

5,10,20

10@2.5MHz

23

6.50

80

AISC-0805F-220

22000@2.5MHz

5,10,20

10@2.5MHz

20

8.00

68

AISC-0805F-330

33000@2.5MHz

5,10,20

10@2.5MHz

17

10.7

60

AISC-0805F-470

47000@2.5MHz

5,10,20

10@2.5MHz

14

13.8

55

AISC-0805F-680

68000@2.5MHz

5,10,20

8@2.5MHz

11

17.5

40

Test Conditions

Inductance (L): Agilent4287A+Agilent16197A or equivalent, 50mV

Direct Current Resistance (DCR): HIOKI 3540 or equivalent

Temperature rise current (Ir): Electric Power, Electric current meter, Thermometer

Irms: Based on temperature rise (∆ T : 20 oC TYP. )
