background image
Data Sheet
AD8237
Rev. 0 | Page 17 of 28
G = 100
HIGH BANDWIDTH MODE
20mV/DIV
100µs/DIV
fCHOP
Figure 52. Small Signal Pulse Response, G = 100, RL = 10 kΩ, CL = 100 pF,
High Bandwidth Mode
G = 1000
HIGH BANDWIDTH MODE
20mV/DIV
1ms/DIV
Figure 53. Small Signal Pulse Response, G = 1000, RL = 10 kΩ, CL = 100 pF,
High Bandwidth Mode
G = 10
HIGH BANDWIDTH MODE
RL = 100kΩ
50mV/DIV
40µs/DIV
100pF
2nF
NO LOAD
560pF
Figure 54. Small Signal Pulse Response with Various Capacitive Loads,
G = 10, RL = 100 kΩ, High Bandwidth Mode
80
60
40
20
0
–80
–60
–40
–20
–40
–25
–10
5
20
125
110
95
80
65
50
35
TEMPERATURE (°C)
NORMALIZED TO 25°C
VS = ±2.5V
Figure 55. Offset Voltage vs. Temperature
50
40
20
10
30
0
–50
–40
–20
–10
–30
–40
–25
–10
5
20
125
110
95
80
65
50
35
TEMPERATURE (°C)
NORMALIZED TO 25°C
GAIN = 1
VS = ±2.5V
VOUT = ±2V
Figure 56. Gain vs. Temperature
1.0
0.8
0.4
0.2
0.6
0
–1.0
–0.8
–0.4
–0.2
–0.6
–40
–25
–10
5
20
125
110
95
80
65
50
35
TEMPERATURE (°C)
NORMALIZED TO 25°C
G = 1
VS = ±2.5V
VCM = ±2V
Figure 57. CMRR vs. Temperature
