Figure 28. Current Noise Spectral Density vs. Frequency

50pA/DIV

1s/DIV

Figure 29. 0.1 Hz to 10 Hz Current Noise

0

5

10

15

20

25

30

100

1k

10k

100k

1M

10M

FREQUENCY (Hz)

G = 1

Figure 30. Large Signal Frequency Response

5V/DIV

0.002%/DIV

750ns TO 0.01%

872ns TO 0.001%

TIME (µs)

2µs/DIV

Figure 31. Large Signal Pulse Response and Settling Time (G = 1), 10 V Step,

5V/DIV

2µs/DIV

640ns TO 0.01%

896ns TO 0.001%

TIME (µs)

0.002%/DIV

Figure 32. Large Signal Pulse Response and Settling Time (G = 10), 10 V Step,

5V/DIV

2µs/DIV

840ns TO 0.01%

1152ns TO 0.001%

TIME (µs)

0.002%/DIV

Figure 33. Large Signal Pulse Response and Settling Time (G = 100),
