100

60

20

40

105

50

0

-40

150

Operating Temperature °C

0

80

Safe Operating Area

100

Selection Guide

Part

Input

Output

Output

Efficiency

Max

Number

Voltage

Voltage

Current

Capacitive

SMD

(3kV)

(VDC)

(VDC)

(mA)

(%)

R1S**-xx3.3

(H)

3.3, 5, 12, 15, 24

3.3

303

75

2200µF

R1S**-xx05

(H)

3.3, 5, 12, 15, 24

5

200

72-78

1000µF

R1S**-xx09

(H)

3.3, 5, 12, 15, 24

9

111

74-78

1000µF

R1S**-xx12

(H)

3.3, 5, 12, 15, 24

12

84

75-80

470µF

R1S**-xx15

(H)

3.3, 5, 12, 15, 24

15

66

75-82

470µF

R1S**-xx24

(H)

3.3, 5, 12, 15, 24

24

42

74-84

220µF

R1D**-xx3.3

(H)

3.3, 5, 12, 15, 24

±3.3

±152

75

±1000µF

R1D**-xx05

(H)

3.3, 5, 12, 15, 24

±5

±100

72-78

±470µF

R1D**-xx09

(H)

3.3, 5, 12, 15, 24

±9

±56

74-78

±470µF

R1D**-xx12

(H)

3.3, 5, 12, 15, 24

±12

±42

75-80

±220µF

R1D**-xx15

(H)

3.3, 5, 12, 15, 24

±15

±33

75-82

±220µF

R1D**-xx24

(H)

3.3, 5, 12, 15, 24

±24

±21

74-84

±100µF

Input Voltage Range

±10%

Output Voltage Accuracy

±2% typ., ±5% max.

Line Voltage Regulation

All Variants

1.2%/1% of Vin typ.

Load Voltage Regulation

3.3V output types

15% typ., 20% max.

(10% to 100% full load)

5V output type

12% typ., 15% max.

9V output type

7% typ., 10% max.

12V, 15V, 24V output types

6% typ., 10% max.

Output Ripple and Noise (20MHz BW limited)

50mVp-p typ., 100mVp-p max.

Operating Frequency

20kHz min. / 60kHz typ. / 100kHz max.

continued on next page

1 Watt SMD

Output

(including Vapor Phase Soldering)

Features

Unregulated

Converters

R1S** : ** without marking denotes 5 pins out of 8 fitted (includes /H option)

** with marking 8 denotes 8 pins out of 8 fitted (/H option not available)

** with marking 12 denotes 10 pins out of 12 fitted (includes /H option)

R1D** : ** without marking denotes 6 pins out of 10 fitted (includes /H option)

** with marking 10 denotes with 10 pins out of 10 fitted (/H option not available)

** with marking 12 denotes 10 pins out of 12 fitted (includes /H option)

UL-60950-1 Certified

EN-60950-1 Certified

EN-60601-1 Certified*

Case and Pinning Options (note restrictions on /H option)

xx = Input Voltage (other input and output voltage combinations available on request)

* add Suffix “H” for 3kV Isolation, e.g.

* add Suffix “P” for Continuous Short Circuit Protection, e.g.

* add suffix -R for tape & reel packing e.g.

R1S_R1D

ECONOLINE

DC/DC-Converter

with 3 year Warranty

The converters are typically used in general purpose and industrial low power isolation and

voltage matching applications where an SMD converter is required.

The converter series feature an extended ambient temperature operating range of

-40°C to +100°C without derating and optional continuous short circuit protection.

In addition to two isolation options and three different case formats, the converters are also

available prepacked as tape and reel for use with automatic insertion machines.

E358085

RoHS

2011/65/EU

6/6

Derating-Graph

(Ambient Temperature)

REV: 1/2016

www.recom-power.com

E-24
