0.1 TO 18.0 GHz

ULTRA BROADBAND

ANALOG DETECTOR

DACP18001

Typical Values @ +25 °C

DACP18001

Wide Frequency Range . . . . . . . . . . . . . . . . . . . . . . . . .

0.1 to 18.0 GHz

Wide Power Range . . . . . . . . . . . . . . . . . . . . . . . . . . . .

-30.0 to +5.0 dBm

Temperature Stability . . . . . . . . . . . . . . . . . . . . . . . . . .

± 0.25 dB

Flatness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

± 0.50 dB

DACP18001

High Frequency CougarPak™ (SMA)

for Analog Detectors

(single-stage)

Teledyne Cougar • 408-522-3838 • 408-522-3839 fax

www.teledyne-cougar.com • cougar@teledyne.com

for Detectors

DC Voltage (no RF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

±22 V

Continuous RF Input Power . . . . . . . . . . . . . . . . . . . . . +14.0 dBm (±5 Vdc)

Operating Case Temperature . . . . . . . . . . . . . . . . . . . .

-55 °C to +100 °C

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . .

-65 °C to +150 °C

Burn-In Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . .

+100 °C

. . . . . . . . . . . . . . .

+3500 °C/Watt

Temperature Rise @ 0 dBm (Tjc) . . . . . . . . . . . . . . . . .

+3.5 °C

Temperature Rise @ +5 dBm (Tjc) . . . . . . . . . . . . . . . .

+35 °C

Guaranteed

Parameter

Typical

0 to 50 °C

-55 to +85 °C

Frequency (Min.)

0.1-18.0 GHz

0.1-18.0 GHz

0.1-18.0 GHz

Input Power Range (Min.)

-30 to +5 dBm

-25 to 0 dBm

-25 to 0 dBm

VSWR (Max.)

1.5:1**

2.0:1**

2.0:1**

Sensitivity, Vout (Min.)

140 mV†

100 mV†

100 mV†

Power Flatness (Max.)

±0.5 dB^

±1.0 dB^

±1.0 dB^

Temperature Stability (Max.)

±0.25 dB

±0.5 dB

±0.5 dB

Output Offset Voltage, no RF (Max.)

±0.3 mV

±1.5 mV

±2.0 mV

1 dB Square Law Departure

-10 dBm

——

Tangential Sensitivity

-45 dBm^^

——

Pulse Response, Pin = -15 dBm

0.3 µsec‡

0.5 µsec‡

0.7 µsec‡

Pulse Response, Pin = 0 dBm

0.5 µsec‡

0.7 µsec‡

1.0 µsec‡

Supply Current, no RF

+3 mA, -3 mA

+4 mA, -4 mA

+4 mA, -4 mA

Supply Current, Pin = +5 dBm

+10 mA, -4 mA

+11 mA, -5 mA

+11 mA, -5 mA

* Measured in a 50 Ohm system at ±5.0 Vdc, 1 MΩ||8 pF unless otherwise specified.

† Pin = –15 dBm. ^ Vout = 100 mV. ^^ 3 dB NF, 1 MHz Bandwidth. ‡ 50% RF to 10 or 90% Video.

** Pin < –15 dBm.

This unit is DC coupled and employs a RF choke at the input (DC short). If the application

calls for the input to sink current there will approximately be an additional 1 mV of output

offset voltage for each 3 mA of current. Sink current should be limited to 250 mA max to

avoid choke burnout.

For higher supply voltages, up to ±22 volts, the positive supply pin must include a series

current limiting resistor Rs = (Vs – 5)/0.01. (e.g.: Vs = 15v, Rs = 1K)

Average power detection is obtained at power levels below approximately –13 dBm.

For best pulse response both supply pins should be bypassed with an additional

1.0 µF capacitor. The unit contains 0.01 µF internal capacitors.
