SPE-14-8-101/C/AD

Page 2 of 3

1. Introduction

The PCB.RPSMAFRA.HT connector was designed to be mounted on a PCB. The maximum

thickness of PCB that the connector can be used with is 0.4mm. The connector pin is directly

soldered onto pads on the PCB. The connector is a standard RP-SMA(F)RA Jack. Taoglas

connectors are all RoHS compliant.

2. Specification

ELECTRICAL

Impedance

50Ω

Frequency Range

DC~6 GHz

Working Voltage

Max. ≤170 Vrms

Dielectric withstanding Voltage

500 Vrms

Insulation Resistance

≥1000M MΩ

MECHANICAL

Connector Dimension

13.75mm*15.1mm

Connector Pin Diameter

1.25 mm

Connector Type

RP-SMA(F)RA Through Hole Jack

ENVIRONMENTAL

RoHS compliant

Operating Temperature

-40°C to +85°C
