ADCMP370/ADCMP371

Preliminary Technical Data

Rev. PrB | Page 2 of 8

SPECIFICATIONS

Parameter

Min

Typ

Max

Units

Test Conditions/Comments

SUPPLY

2.25

5.5

V

Supply Current

2

5

µA

COMMON MODE INPUT RANGE

0

V

INPUT OFFSET VOLTAGE

6

mV

INPUT BIAS CURRENT

10

nA

INPUT OFFSET CURRENT

5

150

nA

OUT VOLTAGE LOW

0.3

V

OUT VOLTAGE HIGH (ADCMP371)

V

OUT LEAKAGE CURRENT (ADCMP370)

1

µA

IN+ > IN-, OUT=22V

TIMING

Propagation Delay

5

10

µs

Input Overdrive=10mV

1

2

µs

Input Overdrive=100mV

ABSOLUTE MAXIMUM RATINGS

Parameter

Rating

-0.3V to +6V

IN+, IN-

-0.3V to +6V

OUT (ADCMP370)

-0.3V to +25V

OUT (ADCMP371)

Operating Temperature Range

-40°C to +125°C

Storage Temperature Range

-65°C to +150°C

146°C/W

Lead Temperature

Soldering (10 sec)

300°C

Vapour Phase (60 sec)

215°C

Infrared (15 sec)

220°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only and functional operation of the device at these or

any other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.
