ECONOLINE

DC/DC-Converter

with 3 year Warranty

RU/RUM

EN-60950-1 Certified

Part

Input

Output

Output

Output

Efficiency

Max

Number

Voltage

Voltage

Voltage

Current

typ.

Capacitive

SIP 7

2kV

(VDC)

(V1VDC)

(V2VDC)

(mA)

(%)

RU-3.30505

(H)

3.3

5

5

100/100

76

470µF/470µF

RU-050505

(H)

5

5

5

100/100

72

470µF/470µF

RUM-3.30505 (H)

3.3

5

5

100/100

78

470µF/470µF

RUM-050505

(H)

5

5

5

100/100

72

470µF/470µF

Other input and output voltage combinations available on request

* add Suffix “P” for Continuous Short Circuit Protection,

e.g. RU-050505/P, RUM-050505/P, RU-3.30505/HP

100

60

20

40

100

50

0

-40

85

150

Operating Temperature °C

0

80

Safe Operating Area

30

1 Watt

SIP7

Isolated

Dual Output

Derating-Graph

(Ambient Temperature)

Features

Unregulated

Converters

Input Voltage Range

±10%

Output Voltage Accuracy

±5%

Line Voltage Regulation

1.2%/1% of Vin typ.

Load Voltage Regulation

15% max

(10%~100% Load)

10% typ.

Output Ripple and Noise (20MHz limited)

RU

75mVp-p max.

Full Load

RUM

100mVp-p max.

Operating Frequency

20kHz min. / 70kHz typ. / 105kHz max.

Efficiency at Full Load

RU

70% min.

RUM

70% min.

Minimum Load = 0%

Specifications valid for 10% minimum load only.

Isolation Voltage

(tested for 1 second)

1000VDC

Input/Output and Output/Output

(rated for 1 minute**)

500VAC / 60Hz

Isolation Voltage

H-suffix

(tested for 1 second)

2000VDC

Input/Output

H-suffix

(rated for 1 minute**)

1000VAC / 60Hz

Output/Output

H-suffix

(rated for 1 minute**)

500VAC / 60Hz

Isolation Capacitance

20pF min. / 94pF max.

Isolation Resistance

10 G

Ω min.

Short Circuit Protection

1 Second

P-Suffix

Continuous

Operating Temperature Range (free air convection)

-40°C to +85°C (see Graph)

Storage Temperature Range

-55°C to +125°C

Relative Humidity

95% RH

Package Weight

2.7g

Packing Quantity

RU

25 pcs per Tube

RUM

30 pcs per Tube

MTBF (+25°C)

using MIL-HDBK 217F

(+85°C)

using MIL-HDBK 217F

Certifications

EN60950-1

Report: SPCLVD1109103

EN60950-1: 2006+A12:2011

Selection Guide

Application Notes chapter "MTBF"

The RU DC/DC converter offers two independent isolated outputs. Typical applications include

multiple channel circuits where inter-channel isolation is also required. The RUM offers

similar specifications in a miniature case for applications where space is at a premium. Both

converters offer 1KVDC input/output isolation and 1kVDC output/output isolation.

The /H versions offer 2kVDC isolation between input and outputs.

Description

Refer to Application Notes

RoHS

2011/65/EU

6/6

**Any data referred to in this datasheet are of indicative nature and based

on our practical experience only. For further details, please refer to our

Application Notes.

REV: 0/2015
