2. Specification

Antenna

Hercules MA510 MIMO

ELECTRICAL

Operation Frequency (GHz)

2.4~2.5

4.8~5.8

Polarization

Linear

Linear

Impedance (ohms)

50

50

Min Isolation (dB)

-22

-28

Max VSWR

2.0:1

2.0:1

Max Return Loss (dB)

-10

-10

Peak Gain (dBi)

3.9

3.0

Efficiency (%)

60

40

Average Gain (dB)

-2.2

-3.9

Radiation Properties

Omni

Omni

Max Input Power

2W max

2W max

MECHANICAL

Dimensions (mm)

Height=29 Diameter=49

Cable

1M RG316- Fully Customizable

Casing

PC

Base and Thread

Nickel Plated Zinc Alloy

Weather proof gasket

CR4305 foam with 3M9448B double-side adhesive

Connector

RP-SMA Male Fully Customizable

Thread Diameter (mm)

18

Sealant

Rubber Stopper

Recommended Torque for

Mounting

24.5N·m

Max Torque for Mounting

29.4N·m

Weight

134g

ENVIRONMENTAL

Protection

IP67 & IP69K

Corrosion

5% NACI for 48hrs- Nickel plated zinc alloy base and thread

Temperature Range

-40ºC to +85ºC

Thermal Shock

100 cycles -40°C to +85°C

Humidity

Non-condensing 65°C 95% RH

Shock (Drop Test)

1m drop on concrete 6 axes

* The Hercules MA510 MIMO antenna performance was measured with RG316 coaxial cable at 1 meter cable length

on a 30x30 cm ground plane.
