4 / 14 page

4 25/07/2016

ICPLW50L

ISOCOM

COMPONENTS

DC93196

ELECTRICAL CHARACTERISTICS (V

CC = 2.7 to 24V, IF = 3mA and TA = -40°C to 105°C,

unless otherwise specified)

SWITCHING

Parameter

Symbol

Test Condition

Min

Typ.

Max

Unit

Propagation Delay Time

to High Output Level

tPLH

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 3.3V,

RL=1.8KΩ, CL = 15pF,

VTHLH = 2V

0.4

1.4

μs

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 5.0V,

RL=2.9KΩ, CL = 15pF,

VTHLH = 2V

0.4

Propagation Delay Time

to Low Output Level

tPHL

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 3.3V,

RL=1.8KΩ, CL = 15pF,

VTHHL = 1.5V

0.3

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 5.0V,

RL=2.9KΩ, CL = 15pF,

VTHHL = 1.5V

0.3

Pulse Width Distortion

|tPHL - tPLH| for any given

device

PWD

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 3.3V,

RL=1.8KΩ, CL = 15pF,

VTHLH = 2V

VTHHL = 1.5V

0.1

1.4

f = 10kHz, Duty Cycle = 50%,

IF = 3mA, VCC = 5.0V,

RL=2.9KΩ, CL = 15pF,

VTHLH = 2V

VTHHL = 1.5V

0.1

Common Mode

Transient Immunity at

High Output Level

CMH

IF = 0mA,

VCC = 3.3V or 5V,

VCM = 1500V p-p

RL=1.8KΩ or 2.9kΩ,

TA = 25°C

kV/μs

Common Mode

Transient Immunity at

Low Output Level

CML

IF = 3mA,

VCC = 3.3V or 5V,

VCM = 1500V p-p,

RL=1.8KΩ or 2.9kΩ,

TA = 25°C

kV/μs
