Series YB2

Panel Seal Pushbuttons

D122

www.nkkswitches.com

Plunger Position

( ) = Momentary

Connected Terminals

Throw & Switch/Lamp Schematics

Pole

Model

Normal

Down

Normal

Down

Notes: Switch is marked with NC, NO, COM, L+, L–.

Lamp circuit is isolated and requires an

external power source.

YB215

YB216

(ON)

1-3

1-2

SPDT

YB225

YB226

(ON)

1-3 4-6

1-2 4-5

DPDT

L (+)

(-) L

L (+)

(-) L

Silver Contacts

Power Level: 3A @ 125/250V AC

Switch base is black

W Panel Seal

(Round and Square)

Solder Lug/

.110” (2.8mm) Quick Connect

Round

Normally Open and Normally Closed

Gold Contacts

Logic Level: 0.4VA max. @ 28V AC/DC max.

Switch base is ivory

6 NC

3 NC

2 NO

5 NO

(COM)

3 NC

2 NO

(COM)

Contact points are both Normally Open and

Normally Closed.

Two o-rings provide

panel seal protection

meeting IP65 of

IEC60529 standards.

POLES & CIRCUITS

CONTACT POINT

PANEL SEAL

SHAPE

BEZEL

CONTACT MATERIALS & RATINGS

TERMINALS

Square

Black

Brushed Chrome

For Round or Square

(7.3)

.288

Epoxy Seal

(2.0)

.079

(1.2)

.047

(2.8)

.110

Thk = (0.5)

.020
