Page: 1/4

Features :

 Excellent load life stability

 High Precision and reliability

 Axial ceramic-silicone coated

 Meets the Standards of MIL-R-26E

 RoHS compliant with 100% lead free

Applications :

 Radar, Ground Vehicles

 Communications systems

 Bias supply, Current shunts, Voltage dropping

 Motor speed controls, Voltage divider networks

 Medical instrumentation and Medical

implantables

Token’s highest quality conformal axial terminal ceramic-silicone

coated KNP-R power resistors for applications requiring high

stability and precision. The KNP-R wire-wound has a low

temperature coefficient and maintain a high degree of stability

under demanding conditions.

The power precision KNP-R series meeting MIL-R-26E (U and V

characteristics) and surface temperature (hot spot) 375℃ max.

Resistors with a wide range of 0.01Ω ~ 82kΩ, covering applications

from precision to power. Products with lead-free terminations meet EU RoHS and China RoHS

requirements.

Operating temperature range is -55℃ ~ +375℃ and derated power at high ambient temperatures as

according to the chart below. Token is equipped to design and produce custom components to meet

many design and reliability demands. In addition to standard military-grade resistor products, we also

have many resistive products designed to meet various source-controlled drawings.

Contact us with your specific needs. Or link to Token official website "General Purpose Resistors" for

more information.

Characteristics U:

275℃ Maximum hot spot temperature. 1% Maximum ΔR in 1000 hours load life.

Characteristics V:

375℃ Maximum hot spot temperature. 3% Maximum ΔR in 1000 hours load life.

Power Wire Wound Resistors Boast Consistent Precision

Power Operation.
