Page: 3/4

Electrical Performance (KNP-P)

Test Items

Test Method

Specifications

Short Time Overload

2.5 times of rated voltage 5 sec.

ΔR±(2%+0.05Ω)

Rated Load

Rated wattage 30 minutes.

ΔR±(1%+0.05Ω)

Voltage Withstanding

500VAC 1 minute.

ΔR±(1%+0.05Ω)

Insulation Resistance

500V

20MΩ

Temp. Cycle

-20℃ ~ 85℃ 5 cycles

ΔR±(1%+0.05Ω)

Soldering After Resistance

235℃ for 3 sec

ΔR±(0.5%+0.05Ω)

Incombustibility

16 times of rated wattage for 5 min.

Not flamed

Load Life

+25℃, 1.5Hrs on ~ 0.5Hrs off cycle, 1000 Hrs.

U: ΔR±(1%+0.05Ω)

V: ΔR±(3%+0.05Ω)

Application Notes of Wire wounds (KNP-R)

 When being used in AC circuits, some wirewound structures give inductance ingredients or parasitic

capacity, so they may cause unusual phenomena such as oscillations etc. Quorum deviations of other

components should be carefully taken into account for use.

 Application and Placement: Wirewound resistors use different gauges of wire as resistance elements.

Sometimes the gauge is extremely thin (finer than a strand of human hair) and very susceptible to breakage

in environments containing salts, ash, dust and corrosives. Avoid utilization in such environments.

 Do not install in dusty areas because the accumulation will cause shorts and poor conductance.

Order Codes (KNP-R)

KNP-R3A

U

100R

B

P

Part Number

KNP-R

Characteristic

(℃)

U

275℃

V

375℃

Resistance Value

(Ω)

0R1

1.0Ω

1R

1Ω

100R

100Ω

1K

1000Ω

Resistance

Tolerance (%)

B

±0.1%

C

±0.25%

D

±0.5%

F

±1%

G

±2%

H

±3%

J

±5%

Package

P

Bulk

TB

Taping Box
