Relay Module - PR2-RSP3-LDP-24DC/4X21AU - 2834766

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Preassembled relay modules with spring-cage connection, consisting of a relay base, industrial relay with

integrated LED, free-wheeling diode and engage/disengage manual actuate lever and retaining bracket. Input

voltage: 24 V DC, four PDTs with gold-plated contacts, 5 A

The figure shows the 24 V DC

version

Why buy this product

 With DC types, freewheeling diode is integrated in relay

 Relay with detectable manual operation and status LED

 Mechanical switch position indicator

 Logical contact arrangement thanks to 1/3-level relay base

 4 PDT types with multi-layer gold contacts

Key Commercial Data

Packing unit

5 STK

GTIN

GTIN

4046356044585

Technical data

Note

Utilization restriction

EMC: class A product, see manufacturer's declaration in the download

area

Dimensions

Width

31 mm

Height

95 mm

Depth

84 mm

Ambient conditions

Ambient temperature (operation)

-25 °C ... 60 °C

Ambient temperature (storage/transport)

-25 °C ... 70 °C
