07/23/2018 Page 2 / 5

Relay Module - PR2-RSP3-LDP-24DC/4X21AU - 2834766

Technical data

Coil side

Nominal input voltage UN

24 V DC

Typical input current at UN

38 mA

Typical response time

13 ms

Typical release time

5 ms

Protective circuit

Damping diode

Operating voltage display

Green LED

Power dissipation for nominal condition

0.91 W

Contact side

Contact type

4 PDTs

Type of switch contact

Single contact

Contact material

AgNi, hard gold-plated

Maximum switching voltage

250 V AC/DC

Minimum switching voltage

1 V

Min. switching current

1 mA

Maximum inrush current

12 A (15 ms)

Limiting continuous current

5 A

Interrupting rating (ohmic load) max.

120 W (at 24 V DC)

110 W (at 48 V DC)

78 W (at 60 V DC)

55 W (at 110 V DC)

77 W (at 220 V DC)

1250 VA (for 250 V AC)

General

Test voltage relay winding/relay contact

2 kV (50 Hz, 1 min.)

Test voltage relay contact/relay contact

2 kV (50 Hz, 1 min.)

Operating mode

100% operating factor

Mechanical service life

5x 107 cycles

Mounting position

any

Assembly instructions

In rows with zero spacing

Connection data input side

Connection name

Coil side

Connection method

Spring-cage connection

Stripping length

10 mm

Conductor cross section solid

0.2 mm² ... 1.5 mm²

Conductor cross section flexible

0.2 mm² ... 1.5 mm²

Conductor cross section AWG

24 ... 16

Standards and Regulations

Standards/regulations

IEC 60664

EN 50178
