1 / 11 page

https://www.phoenixcontact.com/us/products/2902955

09/06/2016 Page 1 / 11

Relay Module - PLC-RSC- 24DC/21 ATEX - 2902955

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PLC-INTERFACE, consisting of DIN rail-mountable basic terminal block with screw connection and plug-in

miniature relay with power contact, 1 PDT, input voltage: 24 V DC, UL/cUL: approved for use in Ex Zone Class I,

Div. 2 and ATEX (Zone 2)

Key Commercial Data

Packing unit

1 STK

Weight per Piece (excluding packing)

25.000 g

Custom tariff number

85364190

Country of origin

Germany

Technical data

Note

Utilization restriction

EMC: class A product, see manufacturer's declaration in the download

area

Dimensions

Width

6.2 mm

Height

80 mm

Depth

94 mm

Ambient conditions

Ambient temperature (operation)

-20 °C ... 60 °C (UL)

-40 °C ... 60 °C (ATEX)

Ambient temperature (storage/transport)

-40 °C ... 85 °C

Coil side

Nominal input voltage UN

24 V DC

Typical input current at UN

9 mA
