09/06/2016   Page 2 / 11

Relay Module - PLC-RSC- 24DC/21 ATEX - 2902955

Technical data

Coil side

Typical response time

5 ms

Typical release time

8 ms

Protective circuit

Reverse polarity protection Polarity protection diode

Free-wheeling diode Damping diode

Operating voltage display

Yellow LED

Power dissipation for nominal condition

0.2 W

Contact side

Contact type

1 PDT

Type of switch contact

Single contact

Contact material

AgSnO

Maximum switching voltage

250 V AC/DC (The separating plate PLC-ATP should be installed for

voltages larger than 250 V (L1, L2, L3) between identical terminal blocks in

adjacent modules. Potential bridging is then carried out with FBST 8-PLC...

or ...FBST 500...)

Minimum switching voltage

5 V (at 100 mA)

Min. switching current

10 mA (at 12 V)

Maximum inrush current

10 A (4 s)

Limiting continuous current

6 A

Interrupting rating (ohmic load) max.

140 W (at 24 V DC)

20 W (at 48 V DC)

18 W (at 60 V DC)

23 W (at 110 V DC)

40 W (at 220 V DC)

1500 VA (for 250 V AC)

Switching capacity in acc. with DIN VDE 0660/IEC 60947

2 A (at 24 V, DC13)

0.2 A (at 110 V, DC13)

0.1 A (at 220 V, DC13)

3 A (at 24 V, AC15)

3 A (at 120 V, AC15)

3 A (at 230 V, AC15)

General

Test voltage relay winding/relay contact

4 kV AC (50 Hz, 1 min.)

Operating mode

100% operating factor

Degree of protection

RT III (Relay)

Mechanical service life

Flammability rating according to UL 94

V0

Designation

Standards/regulations
