FIRETRAP

Check the Wiring required for your Trap:

The FIRETRAP is capable of switching nearly any trap type, however wiring conventions vary between

manufacturers. The relays on the FIRETRAP can switch up to 24V DC or 230V AC @ 5A.

Additional Transmitters

Each transmitter has a unique identity. Each time a transmitter switch is operated, it transmits a secure

RF signal. The Receiver can to set learn this signal and pair it to any of its outputs.

To pair a New Transmitter switch follow this procedure:

Any transmitter button can be paired to one or many of the receiver output relays.

Each button must be paired to each relay individually by following this procedure:

Select the receiver output relay to pair:

1.

Briefly press the receiver pairing switch (S2) once.

2.

The Receiver pairing LED will flash once to indicate output relay 1 is selected.

3.

After the Receiver pairing LED stops flashing, press the receiver pairing switch again to select the

next relay.

4.

Repeat step 2 until the required output relay is selected.

5.

Press the button on the transmitter you want to pair to the selected relay.

6.

The receiver pairing LED will Flash once to confirm pairing is complete.

Erasing Receivers Memory

Press and hold the receiver pairing switch for approx 10 seconds.

Release the switch and watch for the receiver LED to flash to confirm erasing.

Press a button on the transmitter and ensure no relay actives

NOTE: You cannot erase individual transmitters or buttons

Configuring Receiver Relays

The link caps (shown above) configure the outputs operation. The these links are connected/broken us-

ing the small link cap placed over the pins. To “store” the setting turn power off then back on.

Link Positions

Relay Outputs

LK1

LK2

RLY 1

RLY 2

RLY 3

RLY 4

Open

Open

Closed

Open

Mom

Mom

Mom

Open

Closed

Mom

Mom

Mom

Mom

Closed

Closed

-

-

-

-
