DC to 3000 MHz

Matching Pad

Coaxial

Maximum Ratings

Coaxial Connections

Input

N-Male

Output

N-Female

Operating Temperature

-45°C to 100°C

Storage Temperature

-55°C to 100°C

Input Power

2W

Features

• Minimum loss pad

• Wideband coverage, DC to 3000 MHz

• Excellent VSWR

• Rugged unibody construction

Applications

• Impedance matching

UNMP-R5075-33+

Outline Dimensions (

)

inch

mm

Outline Drawing

Connectors Model

50ΩM-N

UNMP-R5075-33+

75ΩF-N

REV. OR

M161440

UNMP-R5075-33+

EDU2639

URJ

170517

Page 2 of 2

Electrical Specifications at 25°C

Typical Performance Data 25°C

CASE STYLE: FF779

Permanent damage may occur if any of these limits are exceeded.

+RoHS Compliant

The +Suffix identifies RoHS Compliance. See our web site

for RoHS Compliance methodologies and qualifications

Parameter

Frequency (MHz)

Min.

Typ.

Max.

Unit

Frequency Range

DC

--

3000

MHz

DC-3000

--

5.7

--

dB

DC-3000

--

±0.15

--

DC-100

--

--

0.2

100-1000

--

--

0.3

1000-3000

--

--

0.4

VSWR

DC-100

--

1.01

1.10

:1

100-1000

--

1.05

1.10

1000-3000

--

1.1

1.20

Input Power

DC-3000

--

--

2

W

B

D

E

wt

.68

2.11

.718 grams

17.27

53.59

18.24

72.5

Electical Schematic

5.0

5.4

5.8

6.2

6.6

7.0

0

500

1000

1500

2000

2500

3000

FREQUENCY (MHz)

UNMP-R5075-33+

INSERTION LOSS

-45C

25C

100C

1.00

1.02

1.04

1.06

1.08

1.10

1.12

1.14

1.16

1.18

1.20

0

500

1000

1500

2000

2500

3000

FREQUENCY (MHz)

UNMP-R5075-33+

VSWR (50� PORT)

-45C

25C

100C

Nominal

50 OHMS

MALE

R2

R1

75 OHMS

FEMALE

10

5.77

1.01

1.00

50

5.78

1.01

1.00

100

5.79

1.00

1.00

300

5.82

1.00

1.01

500

5.84

1.01

1.01

800

5.86

1.02

1.02

950

5.86

1.02

1.03

1000

5.86

1.02

1.03

1200

5.87

1.03

1.04

1500

5.87

1.04

1.05

1800

5.87

1.06

1.06

2000

5.87

1.06

1.07

2300

5.87

1.07

1.07

2500

5.86

1.08

1.08

2800

5.84

1.08

1.08

3000

5.82

1.08

1.08

Frequency

(MHz)

Insertion Loss

(dB)

VSWR

(:1)

50 Ω

75 Ω

1. Attenuation varies by 0.3 dB max. over temperature

2. Flatnes= variation over band divided by 2
