FP6121-RWDG datasheet(5/12 Pages) FITIPOWER

5 / 12 page

FP6121-3.5-DEC-2013

FP6121

fitipower integrated technology lnc.

Electrical Characteristics

(VIN=VOUT+1V, VEN1=VEN2=VIN, CIN=1µF, COUT=1µF, TA=25ºC, unless otherwise specified)

Parameter

Symbol

Conditions

Min

Typ

Max

Unit

Output Voltage Accuracy

IOUT=1mA

-2

Current Limit

ILIMIT

RLoad=1Ω

300

Quiescent Current

IOUT=0mA (Single Channel)

µA

Dropout Voltage (Note2)

VDROP

IOUT=150mA

VOUT=1.5V

910

1100

VOUT=1.8V

750

900

VOUT=2.5V

500

600

VOUT=3.0V

270

330

VOUT=3.3V

230

270

IOUT=300mA

VOUT=1.5V

1600

1920

VOUT=1.8V

1450

1750

VOUT=2.5V

980

1170

VOUT=3.0V

510

610

VOUT=3.3V

400

480

Line Regulation

V T

IOUT=1mA, VIN=VOUT +1V to 5V

0.01

0.20

% / V

Load Regulation (Note3)

V

OUT

IOUT=1mA to 200mA

Ripple Rejection (Note4)

PSRR

VIN=VOUT+1V

fRIPPLE = 10kHz

Output Noise Voltage (Note4)

VNO

COUT=1μF, OUT=0mA

μVRMS

Standby Current

ISTBY

VEN1=VEN2=GND, Shutdown

µA

EN Input Bias Current

IIB

VEN1=VEN2=VIN or GND

100

E “High” Threshold

VIH

Start-up

1.0

E “Low” Threshold

VIL

Shutdown

0.4

Temperature Coefficient

(Note4)

IOUT=1mA, VIN=5V

100

ppm/ºC

Thermal Shutdown

Temperature

(Note4)

TSD

160

ºC

T

Hysteresis

ºC

Note 2：The dropout voltage is defined as VIN-VOUT, which is measured when VOUT drops 2% of its normal value with the

specified output current.

Note 3：Load regulation and dropout voltage are measured at a constant junction temperature by using a 40ms low duty

cycle current pulse.

Note 4：Guarantee by design.
