Technical Data 10649

Effective July 2018

MPI25-V2

High current, low profile, miniature power inductors

Product features

•

High current carrying capacity in a compact

standard 1008 (2520 metric) footprint

•

Magnetically shielded, Low EMI

•

Rugged construction

•

Self resonant frequency (SRF) greater

than 25 MHz

•

Inductance range from 0.33 μH to 4.7 μH

•

Current range from 1.2 A to 7.5 A

•

2.7 mm x 2.2 mm footprint surface mount pack-

age in 1.05 mm, 1.25 mm heights

•

Moisture Sensitivity Level (MSL): 1

Applications

•

Mobile/smart phones

•

Handheld/mobile equipment

•

Tablets/e-readers

•

Digital cameras

•

Wearable devices

•

Notebook/netbook/laptop regulators

•

Portable media players

Environmental data

•

Storage temperature range (Component):

-40 °C to +125 °C

•

Operating temperature range: -40 °C to +125 °C

(ambient plus self-temperature rise)

•

Solder reflow temperature:

J-STD-020 (latest revision) compliant

•

Halogen free, lead free, RoHS compliant

Pb

HALOGEN

HF

FREE
