Cree 4-mm Oval LED

C4SMB-RGY/GGY/BGY

• Tolerance of measurement of luminous intensity is ±15%

COLOR BIN LIMIT (I

• Tolerance of measurement of dominant wavelength is ±1 nm

Red: C4SMB-RGY

Bin Code

Min.(mcd)

Max.(mcd)

U4

1976

2130

V1

2130

2347

V2

2347

2564

V3

2564

2781

V4

2781

3000

W1

3000

3295

W2

3295

3590

W3

3590

3885

W4

3885

4180

X1

4180

4600

Blue: C4SMB-BGY

Bin Code

Min.(mcd)

Max.(mcd)

S3

934

1017

S4

1017

1100

T1

1100

1205

T2

1205

1310

T3

1310

1415

T4

1415

1520

U1

1520

1672

U2

1672

1824

U3

1824

1976

U4

1976

2130

Red

Bin Code

Min.(nm)

Max.(nm)

RB

619

624

Blue

Bin Code

Min.(nm)

Max.(nm)

B3

460

465

B23

462.5

467.5

B4

465

470

B45

467.5

472.5

B5

470

475

INTENSITY BIN LIMIT (I

Green: C4SMB-GGY

Bin Code

Min.(mcd)

Max.(mcd)

X3

5020

5440

X4

5440

5860

Y1

5860

6445

Y2

6445

7030

Y3

7030

7615

Y4

7615

8200

Z1

8200

9150

Z2

9150

10100

Z3

10100

11050

Z4

11050

12000

Green

Bin Code

Min.(nm)

Max.(nm)

G7

520

525

G23

522.5

527.5

G8

525

530

G45

527.5

532.5

G9

530

535

G67

532.5

537.5

Ga

535

540
