Cree 4-mm Oval LED

C4SMB-RGY/GGY/BGY

ORDER CODE TABLE*

C4SMB-BGY

Color

Kit Number

Luminous Intensity (mcd)

Dominant Wavelength

Pack-

age

Min.

Max.

Color Bin

Min.

(nm)

Color Bin

Max.

(nm)

Blue

C4SMB-BGY-CS3U4351

934

2130

B3

460

B5

475

Bulk

Blue

C4SMB-BGY-CS44Q3C1

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B3 (460) to B5 (475)

Bulk

Blue

C4SMB-BGY-CS44Q3S1

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B3 (460) to B4 (470)

Bulk

Blue

C4SMB-BGY-CS44Q4S1

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B4 (465) to B5 (475)

Bulk

Blue

C4SMB-BGY-CT24Q3C1

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B3 (460) to B5 (475)

Bulk

Blue

C4SMB-BGY-CT24Q3S1

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B3 (460) to B4 (470)

Bulk

Blue

C4SMB-BGY-CT24Q4S1

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B4 (465) to B5 (475)

Bulk

Blue

C4SMB-BGY-CS3U4352

934

2130

B3

460

B5

475

Ammo

Blue

C4SMB-BGY-CS44Q3C2

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B3 (460) to B5 (475)

Ammo

Blue

C4SMB-BGY-CS44Q3S2

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B3 (460) to B4 (470)

Ammo

Blue

C4SMB-BGY-CS44Q4S2

Any 4 consecutive sub-bins: S4(1017) - U1(1672)

Any 1 color bin from B4 (465) to B5 (475)

Ammo

Blue

C4SMB-BGY-CT24Q3C2

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B3 (460) to B5 (475)

Ammo

Blue

C4SMB-BGY-CT24Q3S2

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B3 (460) to B4 (470)

Ammo

Blue

C4SMB-BGY-CT24Q4S2

Any 4 consecutive sub-bins: T2(1205) - U3(1976)

Any 1 color bin from B4 (465) to B5 (475)

Ammo

Notes:

1. The above kit numbers represent order codes that include multiple intensity-bin and color-bin codes. Only one

intensity-sub-bin code and one color-bin code will be shipped on each reel. Selected single intensity-bin, single

color-bin codes will be orderable in certain quantities. For example, any four consecutive sub-bins from X4 to Z1

mean only one intensity bin with four sub-bins of the following brightness ranges (X4-Y3, Y1-Y4, Y2-Z1) will be

shipped by Cree. For example, any one-color bin from G7 to Ga means only one color bin (G7 or G23 or G8 or G45

or G9 or G67 or Ga) will be shipped by Cree.
