Cree PLCC4 1 in 1 SMD LED

CLM4B-RKC/AKC

ABSOLUTE MAXIMUM RATINGS (T

Items

Color

Symbol

Absolute Maximum Rating

Unit

Forward Current

Red/Amber

I

F

70

mA

Red/Amber

I

FP

200

mA

Reverse Voltage

Red/Amber

V

R

5

V

Power Dissipation

Red

P

D

210

mW

Power Dissipation

Amber

P

D

182

mW

Operation Temperature

Red/Amber

T

opr

-40 ~ +100

°C

Storage Temperature

Red/Amber

T

stg

-40 ~ +100

°C

Junction Temperature

Red/Amber

T

J

110

°C

Junction/Ambient

Red

R

THJA

270

°C/W

Junction/Ambient

Amber

R

THJA

240

°C/W

Junction/Solder Point

Red

R

THJS

130

°C/W

Junction/Solder Point

Amber

R

THJS

120

°C/W

Electrostatic Discharge

Classification(MIL-STD-883E)

Red/Amber

ESD

Class 2

TYPICAL ELECTRICAL & OPTICAL CHARACTERISTICS (T

Characteristics

Symbol

Condition

Unit

Minimum

Typical

Maximum

Forward Voltage

Red

V

F

I

V

2.5

3.0

Forward Voltage

Amber

V

F

I

V

2.2

2.6

Reverse Current

Red/Amber

I

R

V

μA

10

Dominant Wavelength

Red

λ

D

I

nm

618

624

630

Amber

λ

D

I

nm

587

591

596

Luminous Intensity

Red

λ

D

I

mcd

1120

1700

Amber

I

V

I

mcd

1400

1900
