SPEC NO: DSAI2368

REV NO: V.6B

ATE: JUN/21/2016

PAGE: 1 OF 6

APPROVED: Wynec

CHECKED: Allen Liu

DRAWN: L.T.Zhang

ERP: 1201002822

4.0x0.8mm RIGHT ANGLE SMD LED

ATTENTION

OBSERVE PRECAUTIONS

FOR HANDLING

ELECTROSTATIC

DISCHARGE

SENSITIVE

DEVICES

Part Number: KA-4008ZGS

Green

Descriptions

The Green source color devices are made with InGaN

on Sapphire Light Emitting Diode.

Electrostatic discharge and power surge could damage

the LEDs.

It is recommended to use a wrist band or anti-

electrostatic glove when handling the LEDs.

All devices, equipments and machineries must be

electrically grounded.

Package Dimensions

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is ±0.1(0.004") unless otherwise noted.

3.The specifications, characteristics and technical data described in the datasheet are subject to change without prior notice.

4.The device has a single mounting surface. The device must be mounted according to the specifications.

Features

4.0x1.4x0.8mm right angle SMD LED, 0.8mm thickness.

Low power consumption.

Ideal for backlight and indicator.

Package : 2000pcs / reel.

Moisture sensitivity level : level 3.

RoHS compliant.

Kingbright
