IS25LP032D-RKLE:P 数据表(PDF) 80 Page - Integrated Silicon Solution, Inc |
|
|
|||||||||||||||||||||||||||||
IS25LP032D-RKLE:P 数据表(HTML) 80 Page - Integrated Silicon Solution, Inc |
|
|
80 / 118 page  IS25LP032D IS25WP032D Integrated Silicon Solution, Inc.- www.issi.com 80 Rev. A12 08/04/2020 Figure 8.59 Software Reset Enable and Software Reset Sequence In QPI Mode (RSTEN, 66h + RST, 99h) 66h CE# SCK IO[3:0] 0 1 Mode 3 Mode 0 99h 0 1 8.35 SECURITY INFORMATION ROW The security Information Row is comprised of an additional 4 x 256 bytes of programmable information. The security bits can be reprogrammed by the user. Any program security instruction issued while an erase, program or write cycle is in progress is rejected without having any effect on the cycle that is in progress. Table 8.7 Information Row Valid Address Range Address Assignment A[23:16] A[15:8] A[7:0] IRL0 (Information Row Lock0) 00h 00h Byte address IRL1 00h 10h Byte address IRL2 00h 20h Byte address IRL3 00h 30h Byte address Bit 7~4 of the Function Register is used to permanently lock the programmable memory array. When Function Register bit IRLx = “0”, the 256 bytes of the programmable memory array can be programmed. When Function Register bit IRLx = “1”, the 256 bytes of the programmable memory array function as read only. |
|
