Ver.1.03

CPS-RRY-4PCC

1

CONPROSYS Series

Relay Output Module

CPS-RRY-4PCC

* Specifications,color and design of theproducts are subjecttochange

withoutnotice.

This product is aconfigurablemoduleto provide a function of relay

output interface and operates along withthe configurable type controller

of our CONPROSYSseries. It contains four channels of relay outputs

(FormC) withindependentcommon.

* Thecontentsinthis documentare subjectto changewithoutnotice.

* Visit theCONTECwebsite to checkthelatest details inthe document.

* Theinformation inthedata sheets is as of August, 2019.

Features

Relay outputs (FormC)with independentcommon

This producthas four channels of relay outputs (FormC) with

independentcommon.

Independentcommonterminal provided per channel,capable of

supporting a differentexternal power supply.

Therated load is designedtobe a high-capacity of 240VAC6A, 24VDC

5A per channel.

* Thefollowingratingsneed tobesatisfied inorder tomeetCE,ULsrequirements.Usethe productwithinthese

ratings.

CE:240VAC/3A(Resistive),24VDC/5A(Resistive)

UL:240VAC/6A(Resistive),24VDC/5A(Resistive)

Relay isolation

As bus is isolatedfromthe outputinterfacesby relays,this producthas

excellentnoiseperformance.

Compactdesign

Compact design, 25.2 (W)×94.7(D)×124.8 (H), features flexibility in

installation.

Adaptabletoa temperaturerangebetween -20 and +60°C

Theproductis capable of operating inthetemperaturebetween-20 and

+ 60°C. It canbe installed inthevariousenvironments.

Installation easywith twopieces of terminal supportand DIN rail

Youcan install and remove a terminal connectorwithouta screwdriver so

that it canshorten thetime ofthe replacement.Asthe productcanbe

not only mountedonDIN rail, but also is removable along theside rails,

replacing is simple and easy as well.

Equipped withLED foran operation check

TheproducthasLED for an operationcheck,whichhelps youvisually

confirm thecommunication status of eachinterface.

No electrolytic capacitorbattery

Noelectrolytic capacitor is used.TheConteciscreating theproductwith

a longer life.

Specifications

Function specifications

Item

CPS-RRY-4PCC

Output

Numberofoutputsignalchannels 4(Independentcommon)

Outputformat

Relaycontacts(Form C)output

LED

0-3(Green)

Operatetime(ON)

Within20ms

Releasetime(OFF)

Within20ms

Contactresistance(Initialstate)

125mΩmax.

Relaycontact

spec.*1*2

Ratedload

240VAC6A(resistiveload),24VDC5A(resistiveload)

Maximum

voltage

400VAC,300VDC

Maximum

current

6A(AC),5A(DC)

Mechanicallife

expectancy

10,000,000operationsminormore(Switching times:300

operations/min)

Electrical

lifetime

50,000operationsmin.(Switching times:10operations/min,

withratedload)

Connector

2pieces 5.08mmpitch3-pinterminal

Applicablewire

AWG28-12

LED

Status(Green,Red)

Supplyvoltage

24VDC(±10%)

Currentconsumption

0.1A(Max.)

Physicaldimensions(mm)

25.2(W)×94.7(D)×124.8(H)(Noprojectionincluded)

Weight

250g

Installationmethod

Quickmounting onthe35mmDINrail

*1 TomeetCEsrequirements,theratingshouldbeup to 240VAC/3A(Loadresistor),24VDC/5A(Loadresistor).As

for ULsrequirements,theratingshould beup to 240VAC/6A(Loadresistor),24VDC/5A(Load resistor).Usethe

productwithinthespecifiedratings tosatisfytheserequirements.

*2 Refer tothemaximumswitchingcapacitylistedintheReferenceManual(Hardware)andusetheproduct

withinthespecifiedvoltageandcurrentrange.

Caution

Youcansetthemodulesasyoudesireto theconfigurablecontroller up to 16modules.

Thetotalcurrentconsumptionofthemodulesshouldbeless than3.3A.
