Ver.1.03

CPS-RRY-4PCC

2

InstallationEnvironmentRequirements

Item

CPS-RRY-4PCC

Operating ambienttemperature

-20-+60°C

Operating ambienthumidity

10-85%RH(Nocondensation)

Non-operatingambient

temperature

-20-+60°C

Non-operatingambienthumidity

10-85%RH(Nocondensation)

Floatingdustparticles

Nottobeexcessive

Corrosivegases

None

Line-noise

resistance

Linenoise

SignalLine/±1kV(IEC61000-4-4Level3,EN61000-4-4Level3)

Staticelectricity

resistance

Touch/±4kV(IEC61000-4-2Level2,EN61000-4-2Level2)

Air/±8kV(IEC61000-4-2Level3,EN61000-4-2Level3)

Vibration

resistance

Sweep

resistance

10-57Hz*3/semi-amplitudevibration0.15mm,57-150Hz/2.0G

40minutes eachinX,Y,and Zdirections(JISC60068-2-6-compliant,

IEC60068-2-6-compliant)

Shockresistance

15Ghalf-sineshockfor 11ms inX,Y,and Zdirections

(JISC60068-2-27–compliant,IEC60068-2-27-compliant)

Standard

VCCI ClassA,FCCClassA,

CE Marking (EMCDirectiveClass A,LowVoltageDirective,RoHSDirective),

UL

*3 Whenyouuseanoptionalpowerproduct:10-55Hz(Seethemanualofoptionalpowerproductfor details)

Physical Dimensions

List of Option

Configurable TypeController

CPS-MCS341-DS1-111

Configurable Type CPU module

CPS-MCS341-DS1-131

Configurable Type CPU module+ OPCUA server+

MTConnect

CPS-MCS341G-DS1-130

Configurable Type CPU module+3GWAN

CPS-MCS341Q-DS1-131

Configurable Type CPU module+920MHzLAN

CPS-ECS341-1-011

EtherCAT SlaveModule

DINrailmounting powersupply

CPS-PWD-90AW24-01

DIN rail mountingpowersupply 90[w]

(Input: 100 -240VAC, output: 24VDC3.8 A)

CPS-PWD-30AW24-01

DIN rail mountingpowersupply 30[w]

Input:100 - 240VAC, output: 24VDC1.3 A)

Packing List

Product [CPS-RRY-4PCC] …1

Product Guide … 1

Warranty Certificate …1

SerialnumberLabel …1

3-pin Connector…4

Component Name

No.

Name

Function

1 StackBus

Usedforpowersupplyand communicationwiththeconfigurabletypemodule.

2 LEDIndicator

This indicatesstatusoftheproduct.

3 RelayOutput

connector

This isaconnectorfor relayoutput.(Usethe3-pinconnector,included inthepackage)

25.2

φ4

φ4

[mm]

STATUS

RRY-4PCC

0

1

2

3

0

1

2

3

NC

NO

C

NC

NO

C

NC

NO

C

NC

NO

C

94.7

5.1

2

1

STATUS

RRY-4PCC

0

1

2

3

0

1

2

3

NC

NO

C

NC

NO

C

NC

NO

C

NC

NO

C

3
