SST-90-R Product Datasheet

Part Number Nomenclature

Product Family

LED Emission Area

Color

Package Configuration

Bin kit

SST: Surface mount device,

Encapsulated

SSR: Surface mount device

mounted on an aluminum

star board

<Y>: Color

R = Red

F11: 10.0 mm x 11.0 mm -

Surface mount, shipped in

25 unit trays.

R11: Surface mount device

mounted on an aluminum

star board

Flux and Chromaticity bin kit

code - See available ordering

codes below

SST-90 Bin Kit Order Codes

The following tables describe the bin kit ordering codes available for the SST-90 and SSR-90 products. Each bin kit specifies a minimum

flux as well as specific chromaticity bins allowed. Please note that within each kit a maximum flux is not specified and as a result Luminus

may ship any part meeting or exceeding the minimum flux specification. Shipments will always meet the listed chromaticity bins. For

information on ordering bin kits not listed below, please contact Luminus or an official distributor.

Color

Luminous Flux

Wavelength Bins

Kit Number

Bin Kit Flux

Code

Min. Flux

Red

HG

275

R2, R3, R4, R5

HG100

R3, R4

HG102

HH

350

R2, R3, R4, R5

HH100

R3, R4

HH102

HJ

475

R2, R3, R4, R5

HJ100

R3, R4

HJ102
