SST-90-R Product Datasheet

Optical & Electrical Characteristics4,5

Red

Drive Condition5

3.15 A

Continuous

9.0 A

Continous

Parameter

Symbol

Values6

Unit

Current Density

0.35

1.0

A/mm2

Forward Voltage

F min

1.8

2.1

2.5

F max

2.8

Radiometric Power

r typ

2.4

6.4

Luminous Flux7

V typ

540

1500

Dominant Wavelength7

617

618

FWHM

Δλ

1/2

Chromaticity

Coordinates8,9 (Typ.)

0.685

0.687

0.315

0.313

Relative Output Flux vs. Forward Current

20ms, single pulse,Tj=25C

Forward Current vs. Forward Voltage

20ms, single pulse,Tj=25C

Notes: See page 7
