isc N-Channel MOSFET Transistor
ISCNL247P
ELECTRICAL CHARACTERISTICS
TC=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYPE
MAX
UNIT
V(BR)DSS
Drain-Source Breakdown Voltage
VGS= 0; ID= 0.25mA
100
V
VGS(th)
Gate Threshold Voltage
VDS= 5V; ID= 0.25mA
1.4
2.4
V
RDS(on)
Drain-Source On-Resistance
VGS= 10V; ID= 15A
VGS= 4.5V; ID= 10A
19
28
mΩ
IGSS
Gate-Body Leakage Current
VGS= ±20V;VDS= 0
±
100
nA
IDSS
Zero Gate Voltage Drain Current
VDS= 100V; VGS= 0
VDS= 100V; VGS= 0@TJ= 100℃
1
100
μ
A
VSD
Forward On-Voltage
IS= 15A; VGS= 0
1.2
V
gfs
Transconductance
VDS=5V, ID=15A
42
S
Qg (10V)
Total Gate Charge
VDD=50V, ID=15A, VGS=10V
16
nC
Qg (4.5V)
Total Gate Charge
9
Qgs
Gate to Source Charge
3
Qgd
Gate to Drain (Miller) Charge
3
Ciss
Input Capacitance
VGS=0V, VDS=50V, f=1MHz
840
pF
Coss
Output Capacitance
147
Crss
Reverse Transfer Capacitance
4.9
td(on)
Turn on Delay Time
VDD=50V, ID=15A, VGS=10V,
RG=10Ω
6
ns
tr
Rise time
3
d(off)
Turn off Delay Time
13
tf
Fall Time
3
