MODEL: M2EXDY

M2EXDY SPECIFICATIONS

ES-5170 Rev.1 Page 6/6

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm (inch)

29 (1.14)

94 (3.70)

8

(.31)

124 (4.88)

22 (.87)

6 (.23)

11–M3

SCREW

29.5 (1.16)

2–4.2x5

(.17x.20)

MTG HOLE

6 (.24) deep

DIN RAIL

35mm wide

[4 (.16)]

• When mounting, no extra space is needed between units.

4

8 7

10

11

5

6

1

2

3

9

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Power

Supply

4

+

–

1

2

+

–

V

–

+

200Ω

50Ω

+

No Connection

–

INPUT

2

1

4

7

8

10

11

9

Digital

Computation

Circuit

3

5

6

2-WIRE

TRANSMITTER

MONITOR

(1 – 5V DC)

Current

Limiter

Display

Circuit

CONTROL

SW

Isolation

Output

Driver

Output Setting

DIP SW

+

–

OUTPUT

U(+)

V(–)

POWER

JACK

Base Socket

■ When Used as Current Input

Specifications are subject to change without notice.
