MODEL: KS2V2

KS2V2 SPECIFICATIONS

ES-3608 Rev.10 Page 4/4

https://www.m-system.co.jp/

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]

5

6

7

8

2

1

11

10

3

9

4

[3.5] (.14)

110 (4.33)

7.5

(.3)

48 (1.89)

t

1 ≤ t ≤ 8

(.04 ≤ t ≤.31)

MOUNTING

BRACKET

71.5 (2.81)

40 (1.57)

50 (1.97)

7.8 (.31)

CLAMP

(top & bottom)

DIN RAIL

35mm wide

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

1 1–M3.5

SCREW

PACKING

PANEL

1.5 (.06)

PANEL CUTOUT unit: mm

■PANEL CUTOUT

45

+0.5

0

63 MIN.

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

Display/

Setting

A/D

Converter

+

–

INPUT

7

8

10

11

9

2

3

1

N.C.

N.O.

COM

SET1

N.C.

N.O.

COM

SET2

U(+)

V(–)

POWER

RY

RY

Base Socket

5

6

4

Digital

Computation

Specifications are subject to change without notice.
