MODEL: MFS2

MFS2 SPECIFICATIONS

ES-1383 Rev.6 Page 3/4

http://www.m-system.co.jp/

EXTERNAL DIMENSIONS unit: mm (inch)

72 (2.83)

109 (4.29)

139 (5.47)

[3.3 (.13)]

CLAMP

(top & bottom)

DIN RAIL

35mm wide

• When mounting, no extra space is needed between units.

60 (2.36)

72 (2.83)

7.8 (.31)

2–4.5 (.18) dia.

MTG HOLE

25 (.98) deep

14–M3.5

SCREW

12

5

6

14

11

1

10

15

4

3

2

7

9

8

TERMINAL ASSIGNMENTS unit: mm (inch)

5

6

14

11

1

10

15

3

2

7

9

8

INPUT RESISTOR

(model: REM)

Input shunt resistor attached

for current input.

12 4

SCHEMATIC CIRCUITRY & CONNECTION DIAGRAM

+

–

+

–

Isolation

*

Base Socket

*Input shunt resistor attached for current input.

ANALOG INPUT

4

Low Drift

Amplifier

Digital

Computation

Contact

Input

Output 3

Driver

OUTPUT 3

R

12

5

6

9

15

+

–

Isolation

Output 2

Driver

OUTPUT 2

10

1

+

–

Isolation

POWER LED

Output 1

Driver

OUTPUT 1

11

2

+

–

Isolation

Output 4

Driver

OUTPUT 4

8

3

U(+)

V(–)

POWER

7

14

CONTACT INPUT

CONFIGURATOR

JACK
