Data Sheet
ADL5369
Rev. A | Page 13 of 23
5
7
9
11
13
15
17
0
1
2
3
4
5
6
7
8
9
10
300
400
500
600
700
800
900
1000
1100
RF FREQUENCY (MHz)
CONVERSION LOSS
NOISE FIGURE
VGS = 0, 0
VGS = 0, 1
VGS = 1, 0
VGS = 1, 1
Figure 34. Power Conversion Loss and SSB Noise Figure vs. RF Frequency
0
5
10
15
20
25
30
35
300
400
500
600
700
800
900
1000
1100
RF FREQUENCY (MHz)
VGS = 0, 0
VGS = 0, 1
VGS = 1, 0
VGS = 1, 1
Figure 35. Input IP3 vs. RF Frequency
0
5
10
15
20
25
30
35
40
–30
–25
–20
–15
–10
–5
05
BLOCKER POWER (dBm)
Figure 36. SSB Noise Figure vs.10 MHz Offset Blocker Level
