MODEL: R7HL

R7HL SPECIFICATIONS

ES-7812 Rev.18 Page 4/55

http://www.m-system.co.jp/

■ View of R7HL-PA2Sx

Station Address Setting Rotary SW

Status Indicator LED

Operating Mode Setting DIP SW (SW1)

Terminating Resistor SW

Network, Power Supply

Terminals

■ FRONT VIEW

■ SIDE VIEW

X10

STATION ADD.

CNFG.

1 2 3 4 5 6 7 8

PC Configurator Jack

I/O terminals

RUN

PWR

■ Basic View (except R7HL-DAC16ES, R7HL-PA4E and R7HL-PA2Sx)

X10

STATION ADD.

CNFG.

1 2 3 4 5 6 7 8

10 11 12 13

15 16 17 18

■ SIDE VIEW

■ FRONT VIEW

RUN

PWR

0 1 2 3 4 5 6 7 8 9 A B C D E F

*1. Not available with discrete I/O modules.

*2. Not available with analog I/O modules except R7HL-LC2.

LED 8 through F are not available for 8-point discrete output modules.

Discrete output 7 LED is not available for R7HL-DAC15E.

*3. 10 screw terminals for analog output modules.

Station Address Setting

Rotary SW

Status Indicator

LED

Operating Mode Setting DIP SW (SW1)

PC Configurator Jack *

Discrete I/O Status Indicator LED *

Network, Power Supply

Terminals

I/O terminals *

Terminating Resistor SW
