3 / 40 page

MODEL: R7ML

http://www.m-system.co.jp/

R7ML SPECIFICATIONS

ES-7805 Rev.11 Page 3/40

EMS EN 61000-6-2

RoHS Directive

EN 50581

EXTERNAL VIEW

■ BASIC MODULE

ERR

RUN

PWR

X10

STATION ADD.

B. RATE

CNFG.

1 2 3 4 5 6 7 8

0 1 2 3 4 5 6 7 8 9 A B C D E F

10 11 12 13

15 16 17 18

MECHATROLINK Setting Rotary SW

MECHATROLINK

Connector

Station Address Setting

Rotary SW

Status Indicator LED

Operating Mode Setting DIP SW (SW1)

PC Configurator Jack

Discrete I/O Status Indicator LED

Power Supply Terminals

I/O Terminals*

*1. Not available with analog I/O modules.

*2. 10 screw terminals for analog output modules.

■ FRONT VIEW

89A

MECHATROLINK Connector

■ LEFT SIDE VIEW

■ EXTENSION MODULE

1 2 3 4 5 6 7

Discrete I/O Status Indicator LED

I/O Terminals

• DISCRETE, 8 POINTS
