STD and STB Markers

ORDERING INFORMATION

White/ Yellow

marker

size code

Color

marker

size code

Cable diameter

mm

inches

Color of

applicator

wand

Packed box

STD 01

STB 01

1.00

– 1.40

0.040

– 0.055

Brown

10 wands with 30 identical markers

STD 02

STB 02

1.40

– 1.80

0.055

– 0.071

Grey

10 wands with 30 identical markers

STD 03

STB 03

1.90

– 2.65

0.075

– 0.104

Green

10 wands with 30 identical markers

STD 05

STB 05

2.30

– 3.00

0.091

– 0.118

Natural

10 wands with 30 identical markers

STD 06

STB 06

2.60

– 3.50

0.102

– 0.138

Red

10 wands with 30 identical markers

STD 09

STB 09

3.25

– 4.50

0.128

– 0.177

Blue

10 wands with 30 identical markers

STD 12

STB 12

4.50

– 6.00

0.177

– 0.236

Yellow

10 wands with 30 identical markers

STD 15

STB 15

5.80

– 8.50

0.228

– 0.335

Orange

50 identical markers. Applicator available separately*

STD 17

STB 17

8.50

– 11.50

0.335

– 0.452

Orange

50 identical markers. Applicator available separately*

STD 21

STB 21

11.00

– 15.50

0.433

– 0.610

Grey

50 identical markers. Applicator available separately*

STD 24

STB 24

15.00

– 19.00

0.590

– 0.750

Grey

50 identical markers. Applicator available separately*

APPLICATORS*

Order code

Marker size

Color of applicator

Number of applicators per pack

STD15-Applicator

15

Orange

5

STD17-Applicator

17

Orange

5

STD21-Applicator

21

Grey

2

STD24-Applicator

24

Grey

2

STD COLOR CODE

Y

Yellow

W

White

STB COLOR CODE

Legend

Marker color

Ink color

Legend

Marker color

Ink color

Legend

Marker color

Ink color

0

Black

White

4

Yellow

Black

8

Grey

Black

1

Brown

White

5

Green

White

9

White

Black

2

Red

White

6

Blue

White

3

Orange

Black

7

Violet

White
