PLL601-01

Low Phase Noise PLL Clock Multiplier

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 4

4. Crystal Specifications

PARAMETERS

SYMBOL

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Crystal Resonator Frequency

FXIN

Parallel Fundamental Mode

MHz

Crystal Loading Capacitance

Rating

CL (xtal)

5. Jitter Specifications

PARAMETERS

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Max. Absolute Jitter, peak-to-peak

Short term

±100

Max. Jitter, cycle to cycle

Phase Noise, relative to carrier, 125Mhz(x5)

100 Hz offset

105

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

1kHz offset

125

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

10kHz offset

130

dBc/Hz

Phase Noise, relative to carrier, 125Mhz(x5)

100kHz offset

125

dBc/Hz
