PLL650-05

Low EMI Network LAN Clock

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 09/03/04 Page 2

PIN DESCRIPTIONS

Name

Number

Type

Description

XIN

1

I

XOUT/ENB_125M

2

B

Crystal output. At power-up, this pin latches ENB_125M (output enable

selector for 125MHz output. Disabled when ENB_125M is logical zero. Has

120k

Ω internal pull up resistor.

125MHz

5

O

125MHz output.

75MHz/FS1

7

B

75MHz output. This pin latch FS1 value at power-up. It has 60k

Ω internal

pull up resistors.

ENB_75M

8

I

Output enable for 75Mhz output when high. Disabled when ENB_75M is

logical low. It has 60K

Ω internal pull up resistor.

SS0

9

I

This pin is a tri-level input pin to control the spread spectrum function. See

Spread Spectrum Selection Table

SDRAMx2

11

O

SDRAM outputs with double drive strength determined by FS(0:1) value.

25MHz/FS0

14

B

25MHz (reference) output. This pin latch FS0 value at power-up. It has 60k

Ω

internal pull up resistors.

VDD

4,10,15,16

P

Power supply.

GND

3,6,12,13

P

Ground.

SPREAD SPECTRUM SELECTION TABLE

SS0

SST

0

±0.75% Center

M

OFF

1

±0.5% Center

FUNCTIONAL DESCRIPTION

Selectable spread spectrum and output frequencies

The PLL650-05 provides selectable spread spectrum modulation and selectable output frequencies. Selection is made by

connecting specific pins to a logical “zero” or “one”, or by leaving them not connected (tri-level inputs or internal pull-up)

according to the frequency and spread spectrum selection tables shown on pages 1 and 2 respectively.

In order to reduce pin usage, the PLL650-05 uses tri-level input pins. These pins allow 3 levels for input selection: namely, 0

(Connect to GND), 1 (Connect to VDD), M (Do not connect). Thus, unlike the two-level selection pins, the tri-level input pins are

in the “M” (mid) state when not connected. In order to connect a tri-level pin to a logical “zero”, the pin must be connected to

GND. Likewise, in order to connect to a logical “one” the pin must be connected to VDD.

Connecting a bi-directional pin

A bi-directional pin serves as input upon power-up, and as output as soon as the inputs have been latched. The value of the

input is latched-in upon power-up. Depending on the pin (see pin description), the input can be tri-level or a standard two-level.

Unlike unidirectional pins, bi-directional pins cannot be connected directly to GND or VDD in order to set the input to "0" or "1",
