PLL600-27B

Ultra Low Current XO 10 MHz to 52 MHz

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 11/03/05 Page 2

^ Internal Pull-up, default value is ‘1’ when not connected.

PACKAGE PIN DESCRIPTION

Pin No.

Pad

Type

Description

Name

SOIC-8

SOT-6

No.

X (

µm)

Y (

µm)

XIN/FIN

1

3

1

94.18

768.60

I

Crystal input or reference clock input pin.

OE

2

1

2

94.16

605.03

I

Output Enable input. See Table on page 1.

DNC

3

-

4

94.18

331.76

-

Do Not Connect.

GND

4

2

3

94.19

140.38

P

Ground connection.

CLK

5

6

5

715.31

203.87

O

Output clock.

VDD

6

5

6

715.31

455.73

P

Power supply connection.

DNC

7

-

7

715.47

626.72

-

Do Not Connect.

XOUT

8

4

8

476.91

888.88

O

Crystal output.

OE has internal pull-up resistor, so the default value is ‘1’ when not connected.

ELECTRICAL SPECIFICATIONS

1. Absolute Maximum Ratings

PARAMETERS

SYMBOL

MIN.

MAX.

UNITS

Supply Voltage

4.6

V

Input Voltage, dc

-0.5

V

Output Voltage, dc

-0.5

V

Storage Temperature

-65

150

°C

Ambient Operating Temperature*

-40

85

°C

Junction Temperature

125

°C

Lead Temperature (soldering, 10s)

260

°C

ESD Protection, Human Body Model

2

kV

Exposure of the device under conditions beyond the limits specified by Maximum Ratings for extended periods may cause permanent damage to the

device and affect product reliability. These conditions represent a stress rating only, and functional operations of the device at these or any other

conditions above the operational limits noted in this specification is not implied.

* Note: Operating Temperature is guaranteed by design for all parts (COMMERCIAL and INDUSTRIAL), but tested for COMMERCIAL grade only.
