PLL502-35/-37/-38/-39

750kHz – 800MHz Low Phase Noise Multiplier VCXO

Universal Low Phase Noise IC’s

47745 Fremont Blvd., Fremont, California 94538 Tel (510) 492-0990 Fax (510) 492-0991 www.phaselink.com Rev 01/19/06 Page 2

FREQUENCY SELECTION TABLE

SEL3

SEL2

SEL1

SEL0

Selected Multiplier

0

0

1

1

Fin x 32

0

1

1

0

Fin / 8

0

1

1

1

Fin x 2

1

0

0

1

Fin / 2

1

0

1

0

Fin / 16

1

0

1

1

Fin x 4

1

1

0

0

Fin / 4

1

1

0

1

Fin x 8

1

1

1

0

Fin x 16

1

1

1

1

No multiplication

Note: SEL0 is not available (always “1”) for PLL502-35 and PLL502-38 in 3x3mm package

PIN DESCRIPTIONS PLL502-35 and PLL502-38 (see next page of PLL502-37/-39)

Name

TSSOP

Pin number

3x3mm QFN

Pin number

Type

Description

XIN

2

12

I

Crystal input. See Crystal Specification on page 4.

XOUT

3

13

I

Crystal output. See Crystal Specification on page 4.

OE

6

16

I

Output enable pin (see OE logic state table on page 1).

VCON

7

1

I

Voltage Control input.

GND

8,9,10,14

2,3,4,8,11

P

Ground.

CLKT

11

5

O

True output PECL

CLKC

13

7

O

Complementary output PECL.

SEL0

16

Not available

I

SEL1

15

9

I

SEL2

5

15

I

SEL3

4

14

I

Multiplier selector pins. These pins have an internal pull-up

that will default SEL to ‘1’ when not connected to GND.

VDD

1, 12

6,10

P

+3.3V power supply.
